Cessna 182 Skylane

Single engine piston aircraft with fixed gear built from 1956 through 1986 before production ceased for 10 years until they were brought back into production in 1997 until current. Serial Numbers 33000 through 68615 and then 04 through 83061+. The Cessna 182 Skylane seats up to 3 passengers and 1 pilot.



Specifications



Exterior Dimensions

Wing span: 35ft 10in
Length: 28ft
Height: 9ft 3in

Weights

Max TO weight 1956 is 2550. Mx T.O. wt on A-D is 2650lbs. Mx T.O. wt on E-M is 2800lbs.
Empty Weight: 1,540 LBS
Fuel capacity: 55 GAL

Engine

Manufacturer: Cont Motor
Model: O-470 Series (1956-1961 have O-470-L eng. 1962-1974 have O-470-R eng. 1975 & 76 have O-470-S eng. 1977 & newer have O-470-U.)
Horsepower: 230 HP
Overhaul (HT): 1,500 Hrs (2000hr TBO allowed on O-470-U engines if new specs are met.)
Years before overhaul: 12



Performance Specifications for Cessna 182P and Q Models

Horsepower: 230.00Gross Weight: 2,950
Top Speed: 148Empty Weight: 1,754
Cruise Speed: 143Fuel Capacity: 92
Stall Speed (dirty): 50Range: 817

Rate of Climb: 1,010Rate of Climb (One Engine):
Service Ceiling: 16,500Ceiling (One Engine):

TakeoffLanding
Ground Roll: 705Ground Roll 590
Takeoff Roll Over 50 ft: 1,350Landing Roll Over 50 ft: 1,350



Click here to view Performance Specifications for each Model



History

The Cessna 182 Skylane is an American four-seat, single-engined light airplane, built by Cessna of Wichita, Kansas. It has the option of adding two child seats, installed in the baggage area.

Introduced in 1956, the 182 has been produced in a number of variants, including a version with retractable landing gear, and is the second most popular Cessna model still in production, after the 172.

Development

The Cessna 182 was introduced in 1956 as a tricycle gear variant of the 180. In 1957, the 182A variant was introduced along with the name Skylane. As production continued, later models were improved regularly with features such as a wider fuselage, swept tailfin with rear “omni-vision” window, enlarged baggage compartment, higher gross weights, landing gear changes, etc. The “restart” aircraft built after 1996 were different in many other details including a different engine, new seating design, etc.

By mid-2013 Cessna planned to introduce the next model of the 182T, the JT-A, using the 227 hp (169 kW) SMA SR305-230 diesel engine running on Jet-A with a burn rate of 11 U.S. gallons (42 L; 9.2 imp gal) per hour and cruise at 155 kn (287 km/h). Cessna has no timeline for the JT-A and the diesel 172. The normally aspirated, avgas fueled 182 went out of production in 2012, but came back in 2015.

Cessna 182s were also built in Argentina by DINFIA (called A182), and by Reims Aviation, France, as the F182.

Design

The Cessna 182 is an all-metal (mostly aluminum alloy) aircraft, although some parts – such as engine cowling nosebowl and wingtips – are made of fiberglass or thermoplastic material. Its wing has the same planform as the smaller Cessna 172 and the larger 205/206 series; however, some wing details such as flap and aileron design are the same as the 172 and are not like the 205/206 components.

Variants

Mx T.O. wt on 1956 is 2550lbs. 1956-1961 have O-470-L eng.

Cessna 182 (1956) sn 33000 through 33842
Initial production version with fixed landing gear, four-seat light aircraft, powered by a 230 hp (172 kW) Continental O-470-L piston engine, gross weight 2,550 lb (1,157 kg) most commonly used by the Civil Air Patrol[citation needed] and certified on 2 March 1956.

Mx T.O. wt on A-D is 2650lbs.

Cessna 182A Skylane (1957-1958) sn 33843-51556
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-L piston engine, gross weight 2,650 lb (1,202 kg) and certified on 7 December 1956.

Cessna 182B Skylane (1959) sn 51557-52358
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-L piston engine, gross weight 2,650 lb (1,202 kg) and certified on 22 August 1958.

Cessna 182C Skylane (1960) sn 52359-53007
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-L piston engine, gross weight 2,650 lb (1,202 kg) and certified on 8 July 1959.

Cessna 182D Skylane (1961) sn 53008-53598
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-L piston engine, gross weight 2,650 lb (1,202 kg) and certified on 14 June 1960.

Mx T.O. wt on E-M is 2800lbs. Electric flaps/Flat floor & rear window. 1962-1974 have O-470-R eng.

Cessna 182E Skylane (1962) sn 53599-54423
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-L or O-470-R piston engine, gross weight 2,800 lb (1,270 kg) and certified on 27 June 1961.

Cessna 182F Skylane (1963) sn 54424-55058
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-L or O-470-R piston engine, gross weight 2,800 lb (1,270 kg) and certified on 1 August 1962.

Cessna 182G Skylane (1964) sn 55059-55844
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-L or O-470-R piston engine, gross weight 2,800 lb (1,270 kg) and certified on 19 July 1963.

Cessna 182H Skylane (1965) sn 55845-56684
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-R piston engine, gross weight 2,800 lb (1,270 kg) and certified on 17 September 1964.

Cessna 182J Skylane (1966) sn 56685-57625
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-R piston engine, gross weight 2,800 lb (1,270 kg) and certified on 20 October 1965.

Cessna 182K Skylane (1967) sn 57626-58505
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-R piston engine, gross weight 2,800 lb (1,270 kg) and certified on 3 August 1966.

Cessna 182L Skylane (1968) sn 58506-59305
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-R piston engine, gross weight 2,800 lb (1,270 kg) and certified on 28 July 1967.

Cessna 182M Skylane (1969) sn 59306-60055
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-R piston engine, gross weight 2,800 lb (1,270 kg) and certified on 19 September 1968.[7] There was also an experimental version of this model with a full cantilever wing.

Cessna 182N Skylane (1970-1971) sn 60056-60825
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-R or O-470-S piston engine, gross weight 2,950 lb (1,338 kg) for take-off and 2,800 lb (1,270 kg) for landing. Certified on 17 September 1969.

1971 model has camber lift wing.

Cessna 182P Skylane (1972-1976) sn 60826-65175
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-R or O-470-S piston engine, gross weight 2,950 lb (1,338 kg) and certified on 8 October 1971.

Cessna 182Q Skylane (1977-1980) sn 65176-67715
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-U piston engine, gross weight 2,950 lb (1,338 kg) and certified on 28 July 1976.

1975 & 76 have O-470-S eng. 1977 & newer have O-470-U. 2000hr TBO allowed on O-470-U engines if new specs are met. 1979 and up have wet wing.

Cessna 182R (1981-1986) sn 67716-68615
Four-seat light aircraft with fixed landing gear, powered by a 230 hp (172 kW) Continental O-470-U piston engine, gross weight of 3,100 lb (1,406 kg) for takeoff and 2,950 lb (1,338 kg) for landing. Certified on 29 August 1980.[7] This variant, along with the 182Q, can alternatively be equipped with the jet fuel burning SMA SR305-230 Diesel engine.

Cessna 182S Skylane (1997-2000) sn 04-80944
Four-seat light aircraft with fixed landing gear, powered by a fuel-injected 230 hp (172 kW) Lycoming IO-540-AB1A5 piston engine, gross weight of 3,100 lb (1,406 kg) for take-off and 2,950 lb (1,338 kg) for landing. Certified on 3 October 1996.

Cessna 182T Skylane (2001-current) sn80945-83061+
Four-seat light aircraft with fixed landing gear, powered by a fuel-injected 230 hp (172 kW) Lycoming IO-540-AB1A5 piston engine, gross weight of 3,100 lb (1,406 kg) for take-off and 2,950 lb (1,338 kg) for landing. It was certified on 23 February 2001 and, as of July 2015, it is the only variant in production.

Cessna T182 (1981-1986) sn 67716-68615
Four-seat light aircraft with fixed landing gear, powered by a turbocharged 235 hp (175 kW) Lycoming 0-540-L3C5D, piston engine, gross weight of 3,100 lb (1,406 kg) for take-off and 2,950 lb (1,338 kg) for landing. Certified on 15 August 1980.

Cessna T182T Skylane (2001-2013) sn 08002-9100
Four-seat light aircraft with fixed landing gear, powered by a turbocharged and fuel-injected 235 hp (175 kW) Lycoming TIO-540-AK1A piston engine, gross weight of 3,100 lb (1,406 kg) for take-off and 2,950 lb (1,338 kg) for landing. Certified on 23 February 2001.

Cessna T182JT-A Turbo Skylane JT-A (2013-2015)
Four-seat light aircraft with fixed landing gear, powered by a 227 hp (169 kW) SMA SR305-230 diesel engine, it burns 11 U.S. gallons (42 L; 9.2 imp gal) per hour of Jet-A fuel and cruises at 156 kn (289 km/h). The model was first flown in May 2013, and as of July 2015, FAA certification is on hold indefinitely. Originally introduced as the Turbo Skylane NXT, Cessna changed the name to avoid confusion with the Remos NXT.

Robertson STOL 182
An aftermarket 182 STOL conversion certified in 1967 that changes the leading edge shape and aileron controls and lowers the stall speed below 35 mph (56 km/h).



Click here to view Performance Specifications for each Model
